HDMI Cable Tester tester
HDMI Cable Tester tester
REF: HC093
Specifications
- Local module for checking loose cables.
- It has 2 HDMI A female connectors.
- Test push button.
- ON/OFF switch.
- LEDs for each of the threads and numbered from 1 to 19.
Watch video
PVP
€31.77
Price including VAT:
€31.77
PVD
€27.93
PVP: Retail price.
Check conditions.
PVP: Sale price to distributors.
Check conditions.
2 yearswarranty
14 daysreturns
100%safe
Specifications
- Local module for checking loose cables.
- It has 2 HDMI A female connectors.
- Test push button.
- ON/OFF switch.
- LEDs for each of the threads and numbered from 1 to 19.
Related products
Purchased together regularly
More info
Verifier tool for HDMI cables based on type A connector. Two modules are supplied, the local and the remote. The local module has two HDMI A female connectors for checking loose cables where the user has both ends together. The remote module allows the verification of cables already installed, where the ends of the cable are not in the same location. Supplied with carrying case.
Local module specifications
Local module specifications
- Local module for checking loose cables.
- It has 2 HDMI A female connectors.
- Test push button.
- ON/OFF switch.
- LEDs for each of the threads and numbered from 1 to 19.
- Short, cross, open, pass and power LEDs.
- It works with a 9 VDC battery.
- MRemote module for checking installed cables.
- It has HDMI A female connector.
- LEDs for each of the threads and numbered from 1 to 9 and with double function.
- It works with a 9 VDC battery.
- Gross Weight: 170 g
- Product size (width x depth x height): 10.4 x 6.0 x 3.5 cm
- Number of packages: 1
- Packages size: 18.5 x 11.0 x 3.5 cm
- Master-pack: 40
Technical terms
- HDMI
- VDC
- test
- test3
- test3
HDMI
The acronym "HDMI" stands for "High Definition Multimedia Interface".
The HDMI interface allows transmission of video and audio between devices, supporting video resolutions 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p, 1600p.
Different HDMI versions
HDMi 1.0
- December 2002.
- Maximum transfer of 4.9 Gbit/s.
- Supports up to 165 Mpixels/s video mode (1080p or UXGA 60Hz) and 8-channel/192 kHz/24-bit audio mode.
HDMI 1.2
- August 2005.
- Added support for One Bit Audio, used on Super Audio CDs, up to 8 channels.
- Availability HDMI Type A connectors for PC.
HDMI 1.3
- June 2006
- Bandwidth 340 MHz.
- Data rate of 10.2 Gbit/s.
- Dolby TrueHD and DTS-HD,
HDMI 1.4
- Send video and audio HD
- Data and 3D video.
- FullHD to XHD (eXtended High Definition) up to 4096 × 2160 pixels (24 frames per second) or 3840 × 2160 (30 fps).
- Audio Return Channel that will need fewer cables to have a surround sound system connected to the TV.
- Built-in Ethernet connection cable with speeds up to 100 Mbit/s own.
HDMi 2.0
- September 2013
- Bandwidth of up to 18 Gbit/s
- 4K @ 50/60 (2160p) video
- Up to 32 audio channels to a multi-dimensional immersive experience
- Up frequency 1536kHz for maximum audio fidelity sound
- Simultaneous Delivery 2 streaming video to multiple users on the same screen
- Streaming audio up to 4 users
- Support theater angle 21:9 radio
- Dynamic synchronization of video and audio in streaming
- Extensions of CEC commands to control multiple devices from a single point.
Type HDMI
Type A (picture 1): It is the standard connector used in almost all devices.
Type B (picture 2): A connector rarely used.
Type C (picture 3): A connector widely used in tablets, smartphones and other devices.
Type D (picture 4): A connector used in smartphones.
Type E (picture 5): IA connector used for vehicles connectivity.
The HDMI interface allows transmission of video and audio between devices, supporting video resolutions 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p, 1600p.
Different HDMI versions
HDMi 1.0
- December 2002.
- Maximum transfer of 4.9 Gbit/s.
- Supports up to 165 Mpixels/s video mode (1080p or UXGA 60Hz) and 8-channel/192 kHz/24-bit audio mode.
HDMI 1.2
- August 2005.
- Added support for One Bit Audio, used on Super Audio CDs, up to 8 channels.
- Availability HDMI Type A connectors for PC.
HDMI 1.3
- June 2006
- Bandwidth 340 MHz.
- Data rate of 10.2 Gbit/s.
- Dolby TrueHD and DTS-HD,
HDMI 1.4
- Send video and audio HD
- Data and 3D video.
- FullHD to XHD (eXtended High Definition) up to 4096 × 2160 pixels (24 frames per second) or 3840 × 2160 (30 fps).
- Audio Return Channel that will need fewer cables to have a surround sound system connected to the TV.
- Built-in Ethernet connection cable with speeds up to 100 Mbit/s own.
HDMi 2.0
- September 2013
- Bandwidth of up to 18 Gbit/s
- 4K @ 50/60 (2160p) video
- Up to 32 audio channels to a multi-dimensional immersive experience
- Up frequency 1536kHz for maximum audio fidelity sound
- Simultaneous Delivery 2 streaming video to multiple users on the same screen
- Streaming audio up to 4 users
- Support theater angle 21:9 radio
- Dynamic synchronization of video and audio in streaming
- Extensions of CEC commands to control multiple devices from a single point.
Type HDMI
Type A (picture 1): It is the standard connector used in almost all devices.
Type B (picture 2): A connector rarely used.
Type C (picture 3): A connector widely used in tablets, smartphones and other devices.
Type D (picture 4): A connector used in smartphones.
Type E (picture 5): IA connector used for vehicles connectivity.
